The Model X Plus stands as an industrial sublimation printer featuring 8 Kyocera 600 DPI printheads. These printheads can be configured either as dual CMYK or eight colors, encompassing CMYK plus Magenta Fluor, Yellow Fluor, Orange, and Blue. This configuration results in a more extensive range of colors for the final product.

The printer boasts a remarkably proficient speed of up to 250 linear meters per hour (equivalent to 300 2-passes across a 1.5-meter width). It is available in three sizes, contingent on the desired printing width: 3200mm.
Designed to facilitate a transition to industrial digital printing machinery, this machine is a prime choice, embodying all the necessary attributes.

Specification

MODEL	MODEL X plus 3.2
Pringting Technology	Micro Piezo Printing with Variable Dot
Print Head Quantity	8 pieces of industrial heads
Printing Width	2.55M/3.20M
Ink	Sublimation Ink
Colors	4 Colors CMYK
Volume	10L / color
Media	Sublimation Paper
Max. Media Width	2600MM/3200MM
Humidity	55%-70%
Temperature	22℃-28℃
Operating System	WIN 7、WIN 8、WIN 10
Interface	1000MB Ethernet
Display	Human-machine Operation
Rip Software	Ajet Rip
Image Format
File	JPEG/TIF/BMP;
Color Mode	RGB/CMYK
Power Supply	AC380V/3 Phase/5Wires, 50/60HZ
Power Capacity	22KW/25KW
Environment Noise	0DB (It's variable based on the testing distance)
Machine Size & Weight	4.40M2.35M1.93M/2200KG 5.21M2.45M1.93M/2400KG
