Ideal for users who require golden prints on various polyester fabrics that are not frequently washed
Features:
- AT Board
- 16H/20H i3200 is optional for the machine
- Maglev configuration car high-speed running more quiet, stable
- The rubber roller feeds the material without damaging its coating.
- Car anti-collision, both sides of the anti-collision pad
- New all-aluminum ink station, more stable up and down operation
- 1000w high power driver feeding system, 750W feed driver receiving system, better paper receiving
- Receiving and discharging system adopts imported laser sensor to ensure more - stable receiving
- 10L large capacity ink drum
Specification:
| Model |
JC2016 |
| Print Head |
16H Epson i3200 |
| Print Resolution/Speed |
Produce Mode |
277m²/h |
| ResolutionMode |
150m²/h |
| HighResolutionMode |
100m²/h |
| Maximum Print Width |
1800mm |
| Ink |
Sort |
Sublimation lnk |
| Color |
CMYK Glue(5 color) |
| Media |
Width |
1900mm |
| Thickness |
1.5mm to 8mm adjustable |
| Can bear material weight |
1000KG |
| Sort |
Gold foil film |
| High Printing Quality |
VSD technology |
| Media Take-up Device |
10,000 meters of received paper |
| Drying System |
lnfrared Ray Drying System |
| Guide Rail |
THK From Japan |
| Interface |
Three Gigabit nics 1000Mbit/s |
| RIP Software |
Maintop V6.0, Photoprint |
| Voltage |
AC 380 V ± 10 %、50 / 60 ± 1Hz |
| Operation Environments |
Temperature |
15°C-30°C |
| Humidity |
35%RH-65%RH |
| Power |
20500W |
| Dimensions of Printer(LxWxH) |
7000x4000x1701mm |
| Dimensions of Packing(LxWxH) |
Machine |
4100x1500x2120mm |
| Jumbo roll system |
2945x1110x1250mm |
| Oven |
3640x2.280x2150mm |
| Net Weight |
Machine |
960KG |
| Jumbo roll system |
360KG |
| Oven |
900kg |
| Weight |
Machine |
1275KG |
| Jumbo roll system |
450KG |
| Oven |
1400kg |
Details:
A simple and easy-to-install nozzle base plate, along with an integrated adjustable ink station, ensures that the machine maintains a moisturized state when it is not in operation.
THK guide rail guarantees a quieter working environment, smoother movement of the trolley, and less deformation during long-term operation.
By utilizing a CE-certified power supply box and a more reliable switch, we ensure the safety of the electrical system.
Computer configuration:
- CPU AMD 7900
- Asus 650 motherboard
- Memory 32GB(16GBx2)
- Solid State Drive 2T
- Three Gigabit 2.5G network cards
- Chassis AOC CB114
- Power supply AOC DD600
- Voltage regulator with 5kw~8kw above
- Total power of dryer -22Kw, power parameters: 3 phase 4 line 380V
- Wiring requirements: 10 square or more copper wire
Gold foil film:
Fabric:
